Dynacord Professional Install Amplifier 4 x 1250W - High Power Audio System for Churches, Theaters & Live Performances

Product Description

The Dynacord-Install Amplifier 4 x 1250 watts is designed for permanent installs, such as stadiums, churches, theaters, etc. With DSP, runs 48kHz/96kHz incl. FIR Drive. Connections include analog, Dante, and OCA on OMNEO network. Redundancy options included. Channels run in low Z or 70V/100V Direct Drive. Bridge & parallel 2/4 ch. for all speaker types. Digitally controlled interleaved PFC for reliable ops under challenging conditions. Eco Rail mode reduces running costs in idling or light mode.

• 4 x 1250 W multi-channel installation DSP amplifier with digitally controlled PFC supply.
• Fully integrated DSP with high-resolution 96 kHz processing and FIR Drive.
• Dante and OCA integration via OMNEO with fallback options.
• Parallel, bridged and parallel-bridged drive modes with 70/100V/140V/200V and low impedance operation
• High efficiency Eco Rail technology for lower operating costs

Need more info on this product, use this  to submit your request for more information.

Specifications:

User Interface:
Display: Black/White OLED 256 x 64
Front Panel Indicators: 4 x status LEDs (POWER, STANDBY, FAULT, OMNEO)
Front Panel Operating Elements: 3 buttons (UP, ENTER, DOWN)
Rear Panel Indicators: 1 x status LED (STATUS)
Rear Panel Operating Elements: Mains Switch
Power Requirements: 100 V to 240 V, 50 Hz to 60 Hz AC
Power Supply Topology: Switching Mode Power Supply with digital controlled Power Factor Correction
Protections: Audio Limiters, High Temperature, DC, HF, Short Circuit, Back-EMF, Peak Current Limiters, Inrush Current Limiters, Turn-on Delay, Mains Circuit Breaker Protection, Mains Over-/Under voltage Protection
Cooling: Front-to-rear, temperature controlled fans, supervised
Ambient Temperature Limits: +5 °C to +40 °C (+40 °F to +105 °F)
IEC Protection Class: Class I (grounded)
Electromagnetical Environment: E1, E2, E3
Color: Black
