Dynacord DSP Matrix Mix Engine 24x24 - Professional Audio Mixing System for Live Performances & Studio Recording

Product Description

The Dynacord MXE5 kicks off the MXE matrix mix engine line-up. This high-performance audio matrix offers 12 analog mic/line inputs, 8 outputs, and 24x24 Dante channels. Boasting configurable matrix blocks up to 3840 cross-points and 256 internal signals, the MXE5 provides the choice between fixed or free DSP configuration. It also functions as a communications hub, offering comprehensive control of system-wide commands and connecting system devices to IP-based peripherals.

Need more info on this product, use this  to submit your request for more information.

Specifications:

Matrix Size: 36 x 32
Sampling Rate: 48 kHz /96 kHz
Dante In/Out: 24/24

Analog Inputs: 12 mic/line
Analog Outputs: 8
Max. Input/Output Level: + 22 dBu
Signal to Noise Ratio (inputs/outputs): > 118 dB
Signal Processing: 32/40-bit floating point
THD+N: < 0.002 %
Latency (analog in/out, 48 kHz / 96 kHz): < 0.45 ms / < 0.22 ms
Control Ports: 8 GPIO
Dimensions: (w x h x d) 483 x 43.5 x 471 mm (19", 1 RU)
Weight: 6.0 kg (13.2 lbs)

The audio pro needs the Bosch DSP Matrix Mix Engine 24 x 24 Performance Audio Matrix. With its rugged build and advanced software, the Matrix Mix Engine is designed to deliver an unparalleled sound experience. Take your audio production to the next level and create the perfect mix.
